Khoom Description
Qhov no610W hnub ci vaj huam sib luagyog ib feem ntawm peb lub siab -kev ua tau zoo TOPCon bifacial module series, tsim tshwj xeeb raukev siv hluav taws xob- teev hnub ci fais fab nroj tsuag, kev lag luam thiab kev lag luam ru tsev, thiab EPC-tsim cov haujlwmuas xav tau ntev -kev cia siab rau lub sijhawm, kev ua haujlwm ruaj khov, thiab cov khoom lag luam zoo.
Ua nrogN-Type TOPCon technology, a 132 ib nrab - cell layout, thiab adual- iav qauv, qhov module no muab lub zog ntau dua cov txiaj ntsig ib square meter thaum tuav lub zog zoo txhua yam nyob rau hauv ib puag ncig hnyav. Rau qhov project developers thiab EPC cov neeg cog lus, nws muaj kev sib npaug ntawm kev ua tau zoo, durability, thiab tag nrho cov nqi system.
N-Type TOPCon Technology rau Kev Tshaj Tawm Zog Siab dua
Lub module sivN-type TOPCon cells, uas muaj cov txiaj ntsig zoo dua li cov qauv P- hom technologies:
Txo qhov pib degradation (LID) thiab txhim kho kev tiv thaiv mus ntev - lub zog poob
Kev hloov dua siab tshiab ua tau zoo thoob plaws tag nrho lub neej ua haujlwm
Kev ua haujlwm ruaj khov dua nyob rau hauv qhov kub thiab txias thiab qis - teeb pom kev zoo
Rau tej yaam num nrog ntev peev horizons, TOPCon technology muabntau bankable zog tso zisthiab kev sib raug zoo nrog cov kev xav tau nyiaj txiag.
Lub dual- iav qauv tsis yog tsuas yog txhim khu kev ruaj khov tab sis kuj tseem ua haujlwmbifacial zog tsim. Thaum ntsia rau ntawm qhov chaw muaj kev cuam tshuam xws li pob zeb, xuab zeb, lossis lub teeb - xim av, lub module tuaj yeem ntes cov irradiance ntxiv los ntawm sab nraub qaum, ua rau tag nrho cov txiaj ntsig zoo.
Nyob rau tib lub sijhawm, lub2.0mm + 2.0mm tempered iavqauv muaj zog tiv thaiv rau ya raws ingress, UV raug, thiab tshuaj lom neeg corrosion, ua lub module haum rau ntug hiav txwv dej, suab puam, thiab kev lag luam ib puag ncig.
Khoom Parameters -ELECTRICAL DATA (STC)
| Hom qauv | ODA610-33V-MHDRz | ODA615-33V-MHDRz | ODA620-33V-MHDRz | ODA625-33V-MHDRz | ODA630-33V-MHDRz |
|---|---|---|---|---|---|
| Peak zog (Pmax) | 610.00 | 615.00 | 620.00 | 625.00 | 630.00 |
| Lub zog siab tshaj plaws (Vmp) | 40.46 | 40.60 | 40.74 | 40.88 | 41.02 |
| Maximum zog tam sim no (Imp) | 15.08 | 15.15 | 15.22 | 15.29 | 15.36 |
| Qhib Circuit Court voltage (Voc) | 48.68 ±3% | 48.88 ±3% | 49.08 ±3% | 49.28 ±3% | 49.48 ±3% |
| Luv Circuit Court tam sim no (Isc) | 15.96 ±3% | 16.02 ±3% | 16.08 ±3% | 16.14 ±3% | 16.20 ±3% |
| Module Efficiency (%) | 22.6 | 22.8 | 23.0 | 23.1 | 23.3 |
Khoom Parameters - ELECTRICAL DATA(NMOT)
| Hom qauv | ODA610-33V-MHDRz | ODA615-33V-MHDRz | ODA620-33V-MHDRz | ODA625-33V-MHDRz | ODA630-33V-MHDRz |
|---|---|---|---|---|---|
| Peak zog (Pmax) | 462.00 | 466.00 | 469.00 | 473.00 | 477.00 |
| Lub zog siab tshaj plaws (Vmp) | 38.28 | 38.41 | 38.54 | 38.67 | 38.80 |
| Maximum zog tam sim no (Imp) | 12.07 | 12.13 | 12.17 | 12.23 | 12.29 |
| Qhib Circuit Court voltage (Voc) | 46.05 ±3% | 46.24 ±3% | 46.43 ±3% | 46.62 ±3% | 46.81 ±3% |
| Luv Circuit Court tam sim no (Isc) | 12.73 ±3% | 12.80 ±3% | 12.84 ±3% | 12.90 ±3% | 12.97 ±3% |
* NMOT: irradiance 800W / m², AM 1.5, ambient kub 20 degree, cua ceev 1 m / s
Khoom Parameters - ELECTRICAL DATA(BNPI)
| Hom qauv | ODA610-33V-MHDRz | ODA615-33V-MHDRz | ODA620-33V-MHDRz | ODA625-33V-MHDRz | ODA630-33V-MHDRz |
|---|---|---|---|---|---|
| Peak zog (Pmax) | 671.00 | 677.00 | 682.00 | 688.00 | 693.00 |
| Lub zog siab tshaj plaws (Vmp) | 40.46 | 40.59 | 40.75 | 40.88 | 41.04 |
| Maximum zog tam sim no (Imp) | 16.58 | 16.66 | 16.74 | 16.82 | 16.89 |
| Qhib Circuit Court voltage (Voc) | 48.66 ±3% | 48.86 ±3% | 49.06 ±3% | 49.26 ±3% | 49.46 ±3% |
| Luv Circuit Court tam sim no (Isc) | 17.50 ±3% | 17.58 ±3% | 17.66 ±3% | 17.74 ±3% | 17.82 ±3% |
FAQ
Q: Dab tsi yog qhov zoo ntawm TOPCon technology piv rau PERC modules?
A: N- hom TOPCon thev naus laus zis muaj qis qis qis qis qis (LID), txhim kho kev tiv thaiv kom ntev - lub zog poob, thiab kev hloov pauv ntau dua. Piv rau PERC modules, TOPCon panels xa cov khoom siv hluav taws xob ruaj khov dua rau tag nrho cov haujlwm hauv lub neej, ua rau lawv zoo dua rau kev siv hluav taws xob- nplai thiab txhab nyiaj- tej yaam num nyiaj txiag.
Q: Cov ntawv pov thawj dab tsi no lub hnub ci vaj huam sib luag muaj?
A: Lub module tau ntawv pov thawj raws li IEC 61215 thiab IEC 61730 tus qauv thiab ua tau raws li Class II kev ruaj ntseg hluav taws xob. Cov ntawv pov thawj no ua kom ua raws li kev ua lag luam thoob ntiaj teb feem ntau thiab cov kev xav tau ntawm qhov project.
Q: Dab tsi lav tau muab rau cov khoom no?
A: Peb muab 30- xyoo khoom warranty npog cov ntaub ntawv thiab kev ua haujlwm, nrog rau 30-xyoo linear fais fab tso zis warranty, ua kom ntseeg tau ntev thiab kwv yees lub zog tawm los thoob plaws hauv lub neej.
Q: Yuav ua li cas cov modules ntim rau kev thauj mus los thoob ntiaj teb?
A: Cov modules tau ntim rau hauv cov pallets txhawb nqa kom zoo rau lub thawv ntim khoom, txo qhov kev pheej hmoo ntawm kev puas tsuaj thaum lub sijhawm ntev - kev thauj mus los hauv hiav txwv. Ntim configurations muaj rau ob qho tib si 20FT thiab 40HQ ntim.
Q: Dab tsi kev txhawb nqa koj muab ua ntej thiab tom qab xa zaub mov?
A: Peb muab kev pabcuam ua ntej- muag khoom rau kev tsim qauv, kab teeb tsa, thiab cov ntaub ntawv sib tw, nrog rau tom qab- kev muag khoom txhawb nqa rau kev taw qhia kev teeb tsa thiab kev nug txog kev ua haujlwm. Peb pab neeg ua haujlwm pab txhawb EPCs thoob plaws txhua qhov haujlwm.
